Alarm Lock Trilogy DL2700LD - LocDown Pushbutton Cylindrical Door Lock, Straight Lever, Satin Chrome

Alarm Lock has now introduced the new DL2700LD Series featuring Lockdown Indicator and includes Compact Lockdown Keyfob - Ideal for School and Campus Security.





Alarm Lock Trilogy DL2700LD - LOCDOWN STANDALONE ELECTRONIC DIGITAL CYLINDRICAL PIN LOCKS

Buy the Alarm Lock DL2700LD - LocDown Standalone Electronic Digital Cylindrical Pin Locks at discounted prices from Locksandsafes.com. Choose from either a Standard Key Override Model (DL2700LD) or an Interchangeable Core Model (DL2700LDIC).

The Alarm Lock DL2700LD and DL2700LDIC locks have been designed keeping school and campus security in mind. These school security locks come with a Lock-Down Indicator Light Bar and Keyfob. They are ideal for use in K12/Campus Applications. If there is a sign of trouble, remotely pressing a keyfob button will lockdown a classroom or area and lockout any unauthorized access. A large indicator on the inside door confirms that the lock has been activated. A smaller indicator on the outside door also does the same.

The Alarm Lock DL2700LD & DL2700LDIC locks are Grade 1 BHMA Certified with a rugged all metal keypad, which ensures long dependable life. The locks stores upto 100 user codes, which are 100% keypad programmable. Install the lock within an hour and with 5 AA you do not have to worry about changing batteries for up to 3-4 years or 100,000 cycles.

Finishes - The DL2700LD and DL2700LDIC come in US26D Satin Chrome Finish.

FEATURES

At the first sign of trouble, faculty & staff can remotely press their pocket-sized keyfob’s button to lock out unauthorized access, instantly locking-down a classroom or area, while remaining safely within the room. (Keyfob activation up to 100’ away, depending on building construction.) For multi-classroom users, up to 50 keyfobs can be supported on each lock and each keyfob can control up to four locks.

With Trilogy’s lockdown function, only users with a security level of Master or Manager are allowed access and can unlock the lock. All other basic user codes are denied access during emergency lock down. Instantly, a return to normal command, however, can be sent from a keyfob, re-enabling authorized teachers/staff and first responders outside the classroom, thus disabling emergency lockdown at any time.

• Lockdown upto four locks with one compact remote keyfob - Pocket sized, just over 2" (one included with with DL2700LD)
• Bright visual lockdown indicator bar on inner door confirms security activation to occupants. Outside small indicator light flashes and/or optionally beeps when in lockdown.
• Grade 1 Durability. Grade 1 lockset, rugged all metal keypad.
• Upto 100 different user codes (3-5 digits). Master, manager and emergency, plus 3 service codes.
• 100% fingertip programmable, easy installation in less than an hour (Modified ANSI 115 Prep simply retrofits standard locksets.)
• Individual, group or total user code enable/disable. Passage mode, too
• Long-life battery operated; uses 5 standard AA batteries
• Non-handed for easy installation and versatility

OPERATIONS

REMOTE KEYFOB FOR LOCKDOWN: 4-Button Keyfob (2 3/8” x 1 1/4” x 1/2”), controls up to 4 locks and uses replaceable battery. One included with DL2700LD Lock; up to 50 can be supported on each lock. Additional keyfobs, order part no. RR-4KEYFOB. Portable keyfob range up to 100’, depending on building construction constraints.

INDICATORS: Activating LocDown mode via keyfob illuminates a large,red super-bright indicator bar on lock back, & red indicator light, on front. Additional, audible lock-down indicator tone is a programmable option. Routine momentary green visual/audible entry indicator activated with authorized lock usage; visual indicator warns of low battery condition.

Clutch mechanism permits turning lever without retracting latch and reduces stress on lock bodies and spindle. Outside lever free turning in locked position. Entering access code, key bypass, or remote bypass will allow lever to retract latch. Inside lever always instant egress.

TECHNICAL DATA

DOOR THICKNESS: 1 5/8" to 1 7/8." Other thicknesses. Please consult Alarm Lock.
BACKSET: 2 3/4" Standard. 2 3/8" backset also available.
KEYPAD: All metal, 12 button programmable for multi-level access functions including group or individual user codes, master and management codes, passage and emergency or service code, lockout and remote override capability and allowable entry time from 5 to 20 seconds. 4 Different keypad tones and keypad may be silenced.
STANDARD KEY OVERRIDE CYLINDERS:
Solid brass 6 pin tumbler cylinder pinned 5, SC1 keyway, furnished in all locks. Additional tailpieces included: HW580 fits Schlage, Corbin/ Russwin CL, Sargent 480 Series, ASSA65-611. Model HW620 fits Ilco and Lori cylinders.
INTERCHANGEABLE CORE MODELS: Accepts 6 & 7 Pin Cylinders from: Best, Arrow, KSP, Medeco Keymark & Kaba Peaks. Also available IC Core models for Yale, Medeco, Sargent, Corbin/Russwin CL and Schlage. Alarm Lock Tailpiece is supplied; IC Core is not included.
LATCHBOLT: UL Listed, fire rated, 3 hours, 1/2” throw, solid brass, deadlocking. Reversible. Adjustable front for flat or beveled doors.
STRIKE: 1 1/8” x 2 3/4” T strike & 1 1/4” x 4 7/8” ASA strike included. With screws for wood or metal jambs.
LATCH FRONT: 1 1/8” x 2 1/4” wrought brass or stainless steel.
HANDING: Non-handed.
FINISHES: US26D Satin Chrome US10B Duronodic
Click here to see our Definitive List of Door Hardware Finishes
POWER: 5 AA alkaline batteries (supplied), provide up to 3-4 years long battery life &/or approximately 100,000 cycles, typ., engaging Trilogy's unique Flex Drive motor, depending on actual lock usage. Audible low battery alert.
DOOR PREP: Standard ANSI A115 Series Prep, modified by adding additional through-bolt holes. Cleanly, simply retrofits standard locksets.
COMPLIANCES: Grade I, heavy duty cylindrical lockset, UL listed and FCC certified. ADA compliant leversets.
