Yale NTB633 | Grade 1 NexTouch Cylindrical Lock with Pushbutton Keypad, Without Cylinder Override

Yale NTB633 | Grade 1 NexTouch Cylindrical Lock with Pushbutton Keypad, Without Cylinder Override

FUNCTION

Without Cylinder Override

• For doors that do not require mechanical key override.

• Latchbolt retracted by lever outside with valid PIN code, or by operating lever inside.

• Inside lever always active.

• Deadlocking latchbolt.

OPTIONS

DPS - Door Position Switch

An Auxiliary Door Position Sensor (DPS) must be installed with the lock to enable both Escape Return and Privacy functions.

LEVERS

FEATURES

Choice of capacitive touchscreen or tactile pushbutton keypad

Touchscreen responds to human touch, enabling convenient entrance or access to programming menu. Pushbutton keypad option also available for more tactile requirements, such as ADA compliance.

Keyless entry and management

Reduces complexity of key system management

PIN code access

Installations are able to be programmed with up to 500 unique PIN codes and a master code for access to programming.

Modular technology

Allows for upgrade to more advanced security technologies with Data-on-Card as requirements change and grow.

Works with cloud-based management software

Single system enables use from anywhere with Internet access from a range of devices, including your computer, smartphone or tablet.

Audit trail

Lifetime audit trail stored within the software to know exactly who has accessed the lock when.

Voice-guided programming in 3 languages

Voice-guided prompts make updates straightforward and effortless in English, Spanish or French.

Three (3) volume modes

Playback can be set for normal, low or silent.

Privacy feature with Door Position Sensor

By holding the interior lock button down for 1.5 seconds, the exterior keypad is temporarily disabled ensuring complete privacy and no additional entry.

Weather resistant gasket seal

Lock is operational even in outdoor settings, in temperatures ranging from -40°F to 140°F (-40°C to 60°C) at 95% relative humidity.

Low battery indicator

Blinking designation signals internal 4 AA alkaline batteries are low.

9V battery power backup feature

With the touch of a 9V battery to the designated area on the front of the lock, your nexTouch® can be powered up for onetime entry.

Hardwire power capable

Can be powered externally using remote 9VDC power supply and plug-in wall transformer.

Keypad lockout feature

Deters tampering by disabling the keypad for a default of 180 seconds after five (5) successive failed attempts.
