Description
Application:
- Double hinge for hanging two entrance doors from a fixed mullion
- Security moldings
- 1/16" (1.5 mm) inset
SPECIFICATION
Clearance:
- 1/32" (1 mm) minimum recommended for hinge side
- Plus standard lockside clearance
- 1-5/8" (41 mm) minimum frame face required plus 3/16" (5 mm) rotational clearance
Fasteners:
- 1/4-20 x 1-1/4" Sexbolt (Screw + Post) - (total for both 052A and 052B)
- #12-24 X 11/16" Pan Head Self-Drill Screws
Length Options: Standard and Custom
Door Reinforcement: None required
Frame Reinforcement: None required to 200 lbs. Heavier weigh use 16-gauge channel.
Fire Rating: Up to 3 hr. metal and 90 min. wood composite (with studs)
Warranty: All Roton products have a lifetime warranty. When ordering electric Roton, the electric portion of the hinge has a one-year warranty.
Material: Aluminum 6063-T6
