Adams Rite
Adams Rite 4565 Series Deadlatch Handles for 4300, 4500, 4900 Series Deadlatches with Turn
No reviews yet
Write a Review
Write a Review
Adams Rite
Adams Rite 4565 Series Deadlatch Handles for 4300, 4500, 4900 Series Deadlatches with Turn
Shipping:
Calculated at Checkout
$54.21
Don't see the quantity, finish, or function you are looking for? We can mix, match and "BUILD" the item option set you are looking for - Just call us at 860-537-1328 and our sales staff will assist !
Description
Note: Left Hand Handing is the same as Right Hand Reverse Handing and Right Hand Handing is the same as Left Hand Reverse Handing. See handing chart for clarification. See our Door Handing guide for more information.
Adams Rite 4565 Series Deadlatch Handles with Turn
The 4565 Series Deadlatch Handles easily unlock the 4300, 4500 and 4900 Series Deadlatches. These handles fit solidly into the cylinder hole of Adams Rite deadlatches.
Function
Designed to operate 4300, 4500 and 4900 Series Deadlatches by a natural downward hand movement, these handles incorporate an activator cam disc that mounts on the handles' escutcheon and fits solidly into the cylinder hole of the latch. Not intended for use as a door pull. 4565 handles feature a thumbturn of minimum practical length.
Operation
Rotate lever downward 90° to unlock. When released, lever returns to horizontal. Rotate lever upward 90° to relock. Key operation from outside is not affected. Clutching action prevents damage to internal components.
Features
Handle
Handle of cast aluminum.
Thumbturn of minimum practical length is designed to offer a firm grip to the fingertips. Ideal for doors where the latch is operated infrequently.
Escutcheon
A 1/4" [6.4 mm] square heat-treated spindle is part of escutcheon assembly, which interlocks with the cam plug. Finished to match lever.
4565 has a sloping 1-3/8" x 4" [34.9 mm x 101.6 mm] escutcheon, designed to match the clean lines of a narrow stile door.
Cam Plug
Secured in latch body by cylinder set screw, the plug is also rigidly tied to handle escutcheon by hardened steel pins. Handing can be reversed by removing a spring clip, reversing the cam, and replacing the clip.
Standard Package
Individually packaged with mounting hardware and cam plug handed LH or RH as specified.
Shipping Weight
2 lbs [0.91 kg].
4565 is also available bulk-packed in cartons, up to 100 per carton. Please contact us for more information.
Options
Ordered for left hand (LH) or right hand (RH) door, but is easily reconfigured in the field to accommodate either door swing.
Standard handles are for 1-3/4" [44.5 mm] thick doors. Please contact us for doors up to 3-1/4" [82.6 mm] available by special order.
Available in choice of powder coat 119 to match 335 Black anodized, 121 to match 313 Dark bronze anodized, and 130 to match 628 Clear anodized.
Click here for our Definitive List of Door Hardware Finishes
DOWNLOADS
Click here to download Adams Rite 4565 Catalog
Click here to download Adams Rite 4565 Installation Instructions
Click here to download Adams Rite Price List
